Thermal Module |
Image Sensor |
Vanadium Oxide Uncooled Focal Plane Arrays |
IR Resolution |
160 × 120 (19 200 pixels) |
Pixel Pitch |
17 µm |
Spectral Range |
8 - 14 µm |
NETD |
< 40mK (@ 25 °C,F#=1.0) |
Focal Length |
6.2 mm |
FOV (Field of View) |
25° × 18.7° |
Image Frequency |
25 Hz |
Focus |
Manual |
IFOV (Spatial Resolution) |
2.74 mrad |
Aperture |
F 1.1 |
|
|
Optical Module |
Picture Resolution |
Configurable: 2 MP, 5 MP, 8 MP |
Video Resolution |
640 × 480 |
Focus |
Fixed |
FOV |
25° × 18.7° |
|
|
Image Display |
Display |
640 × 480 Resolution, 3.5" LCD Touch Screen |
Color Palettes |
White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain |
Digital Zoom |
1x, 2x, 4x, 8x |
Image Modes |
Thermal / Optical / Fusion / PIP |
PIP |
Thermal Picture in Optical Picture |
Fusion |
Thermal Picture and Optical Picture Combined |
|
|
Measurement and Analysis |
Object Temperature Range |
-20 °C to 550 °C (-4 °F to 1022 °F) |
Accuracy |
Max (±2 °C, ±2%) |
Measurement Presets |
Center Spot, Hot Spot, Cold Spot, Off |
Point |
10 User Presets |
Line |
1 User Preset |
Area |
3 User Presets |
High Temperature Alarm |
Audible Warning |
Color Alarm (Isotherm) |
Above / Below / Interval / Insulation |
|
|
Storage |
Storage Media |
Removable Micro SD Card (16 GB) |
Image Storage Capacity |
30,000 images |
Image File Format |
JPEG with Measurement Data Included |
Video Storage Capacity |
10 hours |
Video File Format |
MP4 |
|
|
Functions |
Laser Pointer |
Yes |
Laser Type |
Class II |
LED Light |
70 Lumens |
Wi-Fi |
802.11 a/ac/b/g/n (2.4 and 5 GHz) |
Bluetooth |
Bluetooth 4.2 |
Level / Span |
Auto / Manual |
Text Comment |
Max 200 Characters |
Voice Comment |
Max 60 Seconds |
|
|
Power System |
Power Supply |
12 V DC/1.5A, 5V DC/2A (Charging via USB) |
Power Consumption |
4.2 W |
Battery Type |
Dismountable and Rechargeable Li-ion Battery |
Battery Operating Time |
5 Hours Continuous Running |
|
|
General |
Menu Language |
18 Languages - English, German, French, Russian, Korean, Spanish, Portuguese, Italian, Japanese, Hungarian, Czech, Slovak, Polish, Romanian, Danish, Turkish, Traditional Chinese, Arabic |
Working Temperature Range |
-20 °C to 50 °C (-4 °F to 122 °F) |
Storage Temperature Range |
-20 °C to 60 °C (-4 °F to 140 °F) |
Protection Level |
IP54 |
Drop Test Height |
2 m (6.56 ft) |
Interface |
USB Type-C |
Weight |
Approx. 653 g (1.44 lb) |
Dimension |
244 mm × 100 mm × 104 mm (9.6" × 3.9" × 4.1") |
Tripod Mounting |
UNC 1/4"-20 |
